| Air Supply Requirements |
125 ± 25 psi (8.6 ± 1.7 bar)
|
| Power Requirements |
208-230V, 1 phase, 60Hz, 14A, NEMA 20 amp plug, L6-20P
|
| Mount / Demount Tool |
Polymer head w/ Leverless
|
| Bead Loosening Type |
Upper / Lower Roller
|
| Clamping Type |
Center w/ RollerLock
|
| Match Mounting Capable |
Yes
|
| Maximum Tire Diameter |
50”
|
| Rim Diameter Range |
10” – 34”
|
| Maximum Wheel Width |
19”
|
| Weight |
1065 lbs.
|
| Dimensions |
57" L x 53" W x 77" H
|
| Drive |
Variable up to 17 rpm CW / CCW, Torque 700 ft-lbs.
|
