| Camera Connection |
Ethernet cable (data and power)
|
| Quick ID Sensor Dimensions |
8 x 8 x 6
|
| Quick ID Weight |
20 lbs
|
| Camera Trigger |
Quick Tread or Quick Check system
|
| License Plate Location |
Front or rear of the vehicle
|
| Quick ID Mounting Positions |
Center, Off-center, Indoor or Outdoor
|
| License to VIN service |
Authorized CARFAX EULA on file
|
| Light Requirement |
400 lux or greater at point of image capture
|
| Wireless Network Module |
Standard
|
| Vehicle Speed |
2 to 8 mph
|
| Quick Check Cabinet Shipping Weight |
290 lbs.
|
| Monitor Size |
24" Widescreen LCD
|
| HunterNet® |
3 years free access for 1 user
|
| Quick Check Software |
Standard
|
| Wireless Remote |
Standard
|
| VIN Barcode Reader |
Standard
|
| Compact Cabinet Dimensions |
32"W x 65"H x 23"D
|
| Power Line Filter |
Standard
|
| Real-time Specs (delivered by web) |
Web Specs®
|
| Power Requirements |
115/230V, 15 Amp 50/60 Hz 1 Ph
|
| Vehicle Specifications (30 plus years) |
2 years free updates
|
| Processor |
3.06 GHz Intel® Core i3 - 3.1GHz (or greater)
|
| Hard Drive |
120 GB Solid State Hard Drive (or greater)
|
| Operating System |
Windows® 7 - 64 bit
|
| DVD-RW/CD-RW Drive |
Standard
|
| Memory |
4 GB of DDR3 SDRAM
|
| Maximum Ethernet Length |
328 ft.
|
| Internet Connectivity |
10 MBps or greater, wired connection recommended
|
| Printer |
Color Ink Jet Printer
|
| QC Alignment Printout |
Thousands of available options
|
| Quick Tread Shipping Weight |
1723 lbs.
|
| Air Supply Requirements (SI Units) |
90-150 P.S.I (6.2-10.3 bar)
|
| Pedestal Location |
36 - 96 in. form nearest QT1 edge
|
